Wallbox COMMANDER 2

Category: AC CHARGER WALLBOX

Specifications

Powerful EV charge

Up to 22kW of charging capacity

Easy to use

The built-in touchscreen makes it easy to unlock and choose charge settings

Easy to share

Secure shared access with password protection, RFID cards, or the myWallbox app

Connected

Connects to any smart device via Wi-Fi, Bluetooth, Ethernet, or 4G (Optional)

Controllable

Use the myWallbox platform to control multiple chargers and users, access our energy management solutions, benefit from our integrated payment system, and more

Power Sharing

Connect two or more chargers to the same electrical circuit and charge multiple EVs at once with Commander 2 integrated load management intelligence

INSTALLATION PACKAGE

7.4kW POWER TYPE, 22kW POWER TYPE

Details

7.4^kW
POWER TYPE

Supply, Installation, Commissioning & Training
Charge Output Adjustable (3.7kW to 7.4kW)
Installation Available Nationwide Malaysia
With myWalbox App & Account

22^kW
POWER TYPE

Supply, Installation, Commissioning & Training
Charge Output Adjustable (7.4kW to 22kW)
Installation Available Nationwide Malaysia
With myWalbox App & Account

FEATURES

INSTALLATION PACKAGE

7.4^kW
POWER TYPE

EV Junction Box Enclosure
1 Phase 2 Pole MCB 32A (Branded)
1 Phase 2 Pole RCCB 40A (Branded)
1 Phase 2 Pole Isolator Switch 32A (Branded)
Up to 15m of 2.5mm² x 3C PVC Cable c/w PVC Conduit

_{* For non-installation package RM9,088, charger only without wiring cable and electrical wiring works. Testing and Commissioning using a professional EV simulating tester is inclusive.}

22^kW
POWER TYPE

EV Junction Box Enclosure
3 Phase 4 Pole MCB 40A (Branded)
3 Phase 4 Pole RCCB 40A (Branded)
3 Phase 3 Pole Isolator Switch 35A (Branded)
Up to 15m of 6mm² PVC Cable c/w PVC Conduit

_{* For non-installation package RM9,488, charger only without wiring cable and electrical wiring works. Testing and Commissioning using a professional EV simulating tester is inclusive.}

GENERAL SPECIFICATION

Charger	AC
Color	White or Black
Connector type	Type 1 or Type 2
Charging mode	Mode 3
Dimensions	221 X 152 X115 mm (without cable)
Weight	2.4 kg (without cable)
Cable Length	5 m (7m optional)
Grounding Protection	Built-in Earthing (for the 7.4kW version)

CONNECTIVITY & USER INTERFACE

Connectivity	Wi-Fi / Ethernet / Bluetooth / Optional: 3G-4G
User Identification	PIN code / RFID card / myWallbox app
User Interface	Touchscreen / myWallbox app & portal
Charger Status Information	Touchscreen / RGB LED / myWallbox app & portal
Included Features	Power Sharing
Optional Features	Power Boost / Dynamic Power Sharing / MID Meter
Communication Protocol	myWallbox / OCPP 1.6j

ELECTRICAL SPECIFICATION

Maximum Charging Power	7,4 kW (1Phase) / 22 kW (3Phase)
Rated Voltage AC ± 10%	220 V to 240 V (7,4kW) 400 V (11kW and 22kW)
Rated Current	32A (7.4kW - 1Phase) 16A (11kW - 3Phase) 32A (22kW - 3Phase)
Connector Type	Type 1 or Type 2
Cable Section	5 x 10mm²
Configurable Current	from 6A to rated current
Protection Rating	IP54 / IK08
Residual Current Detection	DC 6 mA

Powerful EV charge
Up to 22kW of charging capacity

Easy to use
The built-in touchscreen makes it easy to unlock and choose charge settings

Easy to share
Secure shared access with password protection, RFID cards, or the myWallbox app

Connected
Connects to any smart device via Wi-Fi, Bluetooth, Ethernet, or 4G (Optional)

Controllable
Use the myWallbox platform to control multiple chargers and users, access our energy management solutions, benefit from our integrated payment system, and more

Power Sharing
Connect two or more chargers to the same electrical circuit and charge multiple EVs at once with Commander 2 integrated load management intelligence

Vehicle Charger / Car Charger / Electronic / Charging Stations / Wallbox / Savings /. Wallbox Commander 2 EV Charging Module from Saturn Pyro is the best available in Malaysia. High performance and cost effective Power Energy Meter with 4-quadrant measurement (consumption and generation). Suitable for Medium or Low voltage installations, in both 3 or 4-wire three-phase circuits, two-phase circuits with or without neutral, single-phase circuits or ARON connections. Available in Penang, KL, Selangor, Johor, Sabah, Sarawak & anywhere in Malaysia & Singapore.
